Adams Rite 3090-01-626 3090 eForce Keyless Entry with Keypad, Satin Chrome

• Battery Operated Keyless Entry Control Device
• Housing: The sleek-looking 3090 eForce measures 1-3/4 wide x 15-3/8 high, with Satin Chrome (626) and Powdercoat Dark Bronze (121) finishes.
• Handle: Clutch-protected cast zinc alloy, finished to match housing, field selectable handing.
• Compatible Locking Devices: The 3090 eForce retrofits to Adams Rite MS Deadlocks, 4500 and 4900 Deadlatches and 8000 Series Exit Devices in 31/32 backsets and greater. Additionally, the 3090 eForce-150 is compatible with Yale 7200 Series and Corbin Russwin ED4000 Series exit devices (check model number for availability).
• Options: RSK-3090, Remote activation input cable.
• Standard Package: Individually boxed with installation instructions, manual, and mounting hardware for metal door applications from 1-3/4 to 2-1/4 thick. Shipping weight approximately 5.5 lbs.
• Provides Access Control for Adams Rite Deadlocks, Ceadlatches, and Exit Devices
• Can Operated in Three Modes
• All Programming Accomplished Through Keypad
• Warranted Free From Defects In Workmanship And Materials Under Normal Use And Service

Finish

Satin Chrome

Function

Entry

Series

3000 Series

Color Code

626/US26D

Package Qty

1

Finish Description

Satin Chrome

Product Type

Paddle

ADA Approved

False

Handing

Non-Handed

Battery

4 AA

Warranty

1 Year From Date of Purchase.

Aluminium Bottle Contents

Swinging

ProductType

Manual

Voltage

4 AA

Grade

Grade 1

Door Thickness

1-3/4″ – 2-1/4″

Access Type

Electronic, Standalone

Alternate Part Number-1

143800

Finish code

626

Users

150

Proximity Format

Keypad

Knob/Lever Style

Clutch Lever

Height

2.25

Length

16.5

Width

6

Product Overview Compatible with Adams Rite latches or 8000 Series Exit Devices, Yale 7200 Series, Corbin Russwin ED4000 Series, 626 Satin Chrome
The eForce 3090 Keyless Entry is a battery-operated keyless entry control for Adams Rite deadlocks deadlatches and exit devices that is compatible with aluminum stile steel and wood door applications. The device can accommodate up to 150 users including master supervisor and emergency users plus two one-time codes. The eForce 3090 can operate in three modes Standard Passage and Lockout. All programming is accomplished via the keypad. Device operation is confirmed by both a visual LED light indicator and an audible sound generated by a piezo horn.
