Blum Compact 39C Large Overlay Hinge1″ Overlay Blum Compact 39C Hinge

• The mounting plate and hinge are combined in one unit.
• The mounting plate side of the hinge requires a single #10 mounting screw which is not included. Screws are available under related products. Only one screw is needed per hinge
• For face frame cabinets with a 3/4″ face frame thicknesses.
• This large overlay hinge is adjustable after installation plus or minus 1/8″ in every direction.
• Installs in a 35mm (1-3/8″) diameter cup drilled in the back of the door.
• Bore distanceis 1/8″. The bore distance is the distance between the edge of the door and the edge of the 35mm cup drilled in the back of the door. This dimension is a standard dimension for all compact European hinges.
• Available in five different overlays. If you are replacing hinges, your present overlay will be stamped on the old hinge. If you need to determine the overlay dimension of your door, view the link found under Resources for measurement instructions.
• The C39 Blum overlay hinge side comes with screws and press-in dowels. If your installation does not use “press in” dowels you can remove the dowels and use the wood screws provided.
• The optional cover cap installs onto the mounting plate side of the hinge, giving the hinge a cleaner appearance.

B10100
