GMS K001SC26DA2 Key-In-Knob Cylinder Satin Chrome

Finish

Satin Chrome

Keyway

Schlage C

Cylinder Type

Key-In-Knob/Lever

Finish Description

Satin Chrome

Product Type

Cylinder/IC Core

Series

K001 Series

Alternate Part Number-1

182933

Product Height

1.02 Inch

Product Length

1.35 Inch

Finish Family

Satin Chrome

Included Components

(5) Tailpiece

Keying Type

Keyed Alike In Pairs

Product Material

Solid Brass

Cylinder Body Length

1.35 Inch

Features

Exact pinning specifications as original system; Supplied with multiple tailpieces; Screw-on retaining cap design

For Use With

Schlage Knobs; Levers; Deadbolts and Yale Levers

Color Code

626/US26D

Function

Cylindrical Lever Cylinder

Manufacturer Parent

GMS Industries

Cylinder Keying

Keyed Alike In Pairs

Sub-Series

K001-SC-26D-A2

Height

1.25

Length

2.63

Width

1.81

Product Overview K001 SeriesKnob/Lever Cylinder

With unwavering attention to detail, and meeting OEM specifications, we strive to make our products “The Perfect Fit” for all applications where our customers use our cylinders.

Features:

• Exact pinning specifications as original system

• OEM replacements for Schlage, Yale, Corbin, Kwikset & more

• Solid brass construction

• 21 keyways

• Available in 2 finishes

• Supplied with multiple tailpieces

• Screw-on retaining cap design (except K200)

Specifications: K001:

• Type – Knob/Lever cylinder
• Fits – Schlage knobs, levers, deadbolts and Yale levers*
• Tailpieces – 5 tailpieces

K002:

• Type – Knob/Lever cylinder
• Fits – Fits Arrow knobs and levers
• Tailpieces – 3 tailpieces

K003:

• Type – Knob/Lever cylinder
• Fits – Fits Sargent levers
• Tailpieces – 3 tailpieces

• *Converts to fit Yale levers with KIT-K001YA

Keyways:

• Arrow 1179 – AW
• Assa V-10 – ASV
• Assa Twin 6000 – AST
• Corbin 60 – CB60
• Corbin L4 – CL4
• Kwikset 1176 – KW
• Russwin D1 – RD1

• Sargent LA – SA
• Sargent LA-LD – SAX
• Sargent LB – SLB
• Sargent RA – RA
• Schlage C – SC
• Schlage C123 – G23
• Schlage C145 – G45

• Schlage C-K – SX
• Schlage E – SCE
• Schlage F – SCF
• Segal 9 – SE
• Weiser E – WR
• Yale 8 – YA
• Yale GA – GA

Finishes:

• Satin Brass – 4
• Satin Chrome – 26D

Keying: Keyed alike in pairs:

• A2
• A2-6**

Zero bitted:

• OB
• OB-6**

Keyed different:

• KD
• KD-6**

Special keying:

• KS
• KS-6**

• **Cylinders are 6 pin.

Tailpieces:

• TLP-01 – Tailpiece
• TLP-02 – Tailpiece
• TLP-03 – Tailpiece

• TLP-05 – Breakoff Tailpiece
• TLP-06 – Tailpiece
• TLP-08 – Tailpiece
