Truth Single Arm Casement Operator, Front MountChestnut / Left Hand

• Operator arm attaches to the track channel on the bottom of the window with the round guide “button” located at the end of the operator arm.
• Operator gear housing attaches to the window frame horizontally rather than vertically to the window sill.
• This operator is the front mount type, meaning the screws come through the front face of the operatore. This is opposed to the rear mount type you may alternatively see.
• Crank Handle sold seperately.
• Overall length of operator gear housing and arm assembly (not including crank handle), as shown in photo is 12.5″.
• Length of arm is 9.5″ (measured from the pivot point to the center of the round guide button on the end of the arm).
• Gear housing measures 5-1/2″ by 11/16″ tall by 1-5/8″ wide.
• Guide button diameter is 9/16″.
• The center-to-center spacing for the widest two screw holes is 4-5/16″
• The center-to-center spacing for the narrowest two screw holes is 3-7/8″.

Handing: Some suppliers hand their merchandise differently than others, so please rely on the photos shown on this web page to determine the hand of operator you need. Selecting a handing and finish option from the drop-downs above will show the operator you will receive. If you have any questions please feel free to contact us.
