UNI-T 1000A True RMS Digital Clamp Meter | UT207B

The UNI-T UT207B Digital Clamp Meter provide reliable True RMS measurements for AC/DC voltage up to 1000V and current up to 1000A. This model feature auto-ranging, non-contact voltage (NCV) detection. It also offer a large LCD with backlight for clear readings. The clamp meter safety with CAT III 600V/CAT II 1000V ratings and is ideal for various electrical maintenance tasks.

Specifications & Features:

• AC Current: Up to 1000A (2% 5)
• DC Current: Up to 1000A (2% 5)
• AC Voltage: Up to 1000V (1.2% 3)
• DC Voltage: Up to 1000V (0.5% 5)
• Resistance: Up to 60M (1% 2)
• Capacitance: Up to 60mF (4% 5)
• Frequency: 10Hz~1MHz (0.1% 3)
• Display Count: 6000
• NCV Detection: Yes
• Jaw Opening: 42mm
• Auto Range: Yes
• Data Hold: Yes
• LoZ Mode: Yes
• Backlight: Yes
• Flashlight: Yes
• Auto Power Off: Approximately 15 minutes
• Safety Rating: CAT III 600V/CAT II 1000V
• Power: 1.5V battery (R03) x 3
• Weight: 420g
• Dimensions: 272mm x 81mm x 43.5mm
• Certifications: CE, UKCA, cETLus
