US Lock USX2050D26D 2050 GR2 2-3/8 in. Backset US26D Storeroom Lever SC1 Satin Chrome

Features

Easy Installation

Security/ANSI Grade

ANSI Grade 2 (Better)

Interior/Exterior

Exterior

Included

Drilling Template, Hardware, Installation Instructions

Hardware Finish Family

Silver

General Material

Metal

Door Locks & Knobs Product Type

Storeroom Levers

Door Handing

Universal/Reversible

Commercial/Residential

Commercial

Certifications and Listings

UL Listed

Assembled Width (in.)

6.30

Assembled Height (in.)

3.35

Assembled Depth (in.)

6.56

Application Type

Entry

Manufacturer Warranty

Limited Lifetime Warranty

Warranty

Limited Lifetime Warranty

Finish

US26D – Dull Chrome

Pack Size

1

UNSPSC

46171500

Product Overview

Certified to ANSI/BHMA Standard A156.2. Recommended for commercial applications for barrier-free access. When used as a replacement lock only a screwdriver is needed. Non-handed levers meet California Fire Code requirements for maximum 1/2 in. door-to-handle spacing when installed on 1-3/4 in. T doors. Independent lever return springs prevent lever sag.

• Finish: US26D dull chrome
• Function: storeroom
• Feature: non-clutched
• Handle shape: lever
• Backset: 2-3/8 in. standard
• Latch faceplate: 1 in. x 2-1/4 in.
• ASA strike
• Keyway: SC1
• Door thickness: 1-3/8 in. to 1-3/4 in. (35 mm to 45 mm)
• Removable through-bolts
• UL fire rating: 3-hours
• ANSI grade-2
• Limited lifetime warranty
